Productos

Sensor de desplazamiento láser Modbus RTU FLR-100-RS485 Rango de medición: 150-1000 mm Modo de salida: con cantidad de interruptor y comunicación RS485 (protocolo de soporte Modbus) Precisión de linealidad: Estándar: ± 0.6% F.S; Resolución: 50um a 150 mm; 2 mm a 1000 mm Tamaño de mancha: φ3 mm a 1000 mm Tiempo de respuesta: 2ms/16ms/40ms establecido

Sensor de desplazamiento láser FLR-100-AA Rango de medición: 150-1000 mm Modo de salida: con cantidad de interruptor y corriente 4-20 mM Precisión de linealidad: Estándar: ± 0.6% F.S. Resolución: 50um a 150 mm; 2 mm a 1000 mm Tamaño de mancha: φ3 mm a 1000 mm Tiempo de respuesta: se pueden establecer 2 ms/16ms/40ms

Laser Displacement Sensor Measuring range: 150-1000mm Output mode: with switching and current 4-20mA Linearity accuracy: ±0.3% F.S. (150-450mm); ±0.6% F.S. (450-1000mm) Resolution: 50um at 150mm; 2mm at 1000mm Spot size: Φ3mm at 1000mm Response time: 2ms/16ms/40ms settable

Sensor láser analógico de 0,01 mm, 80-500 mm, 4-20 mA, sensor de distancia de desplazamiento, medición y control integrados del sensor de desplazamiento láser con pantalla digital Rango de medición de 30-1000 mm con una variedad de rangos para elegir Configuración conveniente del panel de operación Pantalla digital OLED Con comunicación analógica y RS485 (compatible con protocolo ModBus) múltiples salidas Precisión lineal de hasta +0,1 % F.S. Resolución hasta 5um

Displacement Distance Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um

FLR-10-RS485 -M Laser Displacement Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linearity accuracy up to ± 0.1% F.S. Resolution up to 5um

FLR-10-RS485 Laser Displacement Sensor Measuring range: 30-100mm Output mode: with switch quantity and RS485 communication (support ModBus protocol) Linearity accuracy: standard type: ±0.3% F.S. (30-100mm); high precision type: ±0.1% F.S. (30-100mm) Repeatability: 10um at 30mm; 0.1mm at 100mm Resolution: 5um at 30mm; 50u m at 100mm Spot size: 1*3mm at 100mm Response time: 2ms / 16ms / 40ms can be set up Ambient light resistance: incandescent light ≥ 3,000lux Operation panel: OLED digital display Temperature drift: ±0.02%F.S./°C

FLR-10-AA 30-100mm Analog4-20mA Laser Displacement Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um

FLR-10-AA-M Laser Displacement Distance Sensor Analog 4-20mA Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um
